IGBT for Servo Controllers and Frequency Converter, with High Current Half-controlled and Braking Capability
IGBT for Servo Controllers and Frequency Converter, with High Current Half-controlled and Braking Capability Back
 PDF

企业微信截图_1768271556389

Introduction Yangjie Technology has launched a special topology module based on the traditional Econo2 packaging semi-controlled rectifier + braking circuit structure. The special topology structure of this module is suitable for the economic control structure of single DC power supply + multi-axis output in servo frequency converter applications, providing a perfect solution for the economic and compact design requirements of the system.
The IGBT chip adopted by the product is based on the new generation of refined trench process platform, which greatly optimizes the on-state voltage drop of the device. The module adopts DBC insulated copper base plate technology, featuring excellent insulation performance, strong thermal conductivity, strong mechanical structure and outstanding heat dissipation performance.
Features 1. Special topological structure of semi-controlled rectification + braking;

2. High-performance GPP wafer combined with thyristor rectifier bridge chip solution;

3. Possess strong surge capability;

4. It uses DBC insulated copper base plate, which has excellent heat dissipation performance;

5. Compact packaging;
SPECIFICATION

MG160TB16E1
